参数：
| 入射角度 |
0° |
波长 |
587.6nm |
|
波长范围 |
430~680nm |
指标 |
430~680nm@Ravg≤0.4% |
|
焦距容差 |
±1% |
光洁度 |
40/20 |
|
中心厚度容差 |
±0.1mm |
面型 |
λ/4 |
常规产品列表：
| 产品型号 |
基材 |
焦距 |
直径 |
中心厚 |
半径R1 |
半径R2 |
光洁度 |
|
D4.4F5 |
ZK7 |
5.00 |
4.40 |
1.30 |
20.23 |
-3.59 |
40/20 |
|
D6F21.4 |
ZF6 |
21.40 |
6.00 |
1.50 |
22.03 |
-58.45 |
40/20 |
|
D6F6.7 |
K9 |
6.70 |
6.00 |
3.56 |
6.22 |
-6.22 |
40/20 |
|
D6.8F11.1 |
ZF10 |
11.10 |
6.80 |
2.50 |
36.14 |
-9.45 |
40/20 |
|
D8F14.1 |
ZK11 |
14.10 |
8.00 |
1.80 |
71.61 |
-10.233 |
40/20 |
|
D8F13.5 |
ZF10 |
13.50 |
8.00 |
2.50 |
27.833 |
-13.50 |
40/20 |
|
D9F15.1 |
ZF7 |
15.10 |
9.00 |
2.40 |
27.11 |
-21.97 |
40/20 |
|
D9.5F14.4 |
K9 |
14.40 |
9.50 |
2.30 |
31.027 |
-9.55 |
40/20 |
|
D10F12.8 |
C7980 |
12.80 |
10.00 |
3.00 |
13.70 |
-18.99 |
40/20 |
|
D10.5F16.5 |
ZF7 |
16.60 |
10.50 |
2.40 |
27.645 |
-24.85 |
40/20 |
|
D13F99.2 |
ZF7 |
99.20 |
13.00 |
3.00 |
93.261 |
-549.858 |
40/20 |
|
D13.5F116 |
ZF7 |
116.00 |
13.50 |
2.79 |
170.31 |
-445.00 |
40/20 |
|
D13.7F33 |
ZF3 |
33.00 |
13.70 |
3.30 |
40.04 |
-56.132 |
40/20 |
|
D14.5F19.7 |
ZLAF50 |
19.70 |
14.50 |
3.34 |
30.83 |
-30.83 |
40/20 |
|
D15F18.8 |
ZK11 |
18.80 |
15.00 |
7.17 |
38.55 |
-16.218 |
40/20 |
|
D15.5F22.6 |
LAK3 |
22.60 |
15.50 |
2.70 |
21.63 |
-72.61 |
40/20 |
|
D20F58.6 |
ZK10L |
58.60 |
20.00 |
8.00 |
43.783 |
-203.597 |
40/20 |
|
D20.5F22.4 |
LAK2 |
22.40 |
20.50 |
4.70 |
82.79 |
-18.664 |
40/20 |
|
D23.5F32.8 |
K9 |
32.80 |
23.50 |
6.13 |
52.16 |
-24.10 |
40/20 |
|
D26F37.3 |
ZBAF20 |
37.30 |
26.00 |
5.50 |
51.128 |
-51.128 |
40/20 |
|
D27F60.20 |
LAK50 |
60.20 |
27.00 |
3.51 |
44.50 |
-219.30 |
40/20 |
|
D37F219 |
ZF7 |
219.00 |
37.00 |
7.50 |
632.34 |
-242.70 |
40/20 |
|
D50F62.9 |
K9 |
62.90 |
50.00 |
14.00 |
229.1 |
-37.07 |
40/20 |
|
D50.8F124.7 |
ZF7LA |
124.70 |
50.80 |
5.82 |
129.44 |
-439.40 |
40/20 |
|
D52F86.5 |
ZK10L |
86.50 |
52.00 |
9.39 |
1080 |
-53.833 |
40/20 |
|
D60F35 |
ZF62 |
35.00 |
60.00 |
17.50 |
59.50 |
-59.50 |
40/20 |
|
D67F116 |
ZBAF5 |
116.00 |
67.00 |
12.72 |
12233.20 |
-82.82 |
40/20 |
|
D70F117.4 |
K9 |
117.40 |
70.00 |
20.00 |
74.8 |
-2502.1 |
40/20 |
|
D75F15.6 |
ZBAF20 |
156.60 |
75.00 |
9.64 |
217.678 |
-217.678 |
40/20 |
|
D80F235.7 |
K9 |
235.70 |
80.00 |
10.74 |
241.77 |
-241.77 |
40/20 |
|
D85F149.7 |
ZBAF3 |
149.70 |
85.00 |
12.69 |
445.00 |
-124.833 |
40/20 |
|
D105F175 |
ZK10L |
175.00 |
105.00 |
16.21 |
500.00 |
-137.25 |
40/20 |
|
D124F180 |
ZK9 |
180.00 |
124.00 |
22 |
153.11 |
-391.128 |
40/20 |
